DCA-100SSJU — PARTS AND OPERATION MANUAL (STD)— REV. #2 (05/03/01) — PAGE 77
NO. PART NO. ITEM QTY. REMARKS
1 0602220196 BATTERY ........................................ 1 ........... 4D-2
2 M9310500404 BATTERY SHEET 1
3 M9103000504 BATTERY BAND 1
4 0602220921 BATTERY BOLT SET 2
5 0040006000 LOCK WASHER 2
6 M3346900004 BATTERY CABLE 1
7 M3346900104 BATTERY CABLE 1
8 CABLE 1
9 0017112025 HEX. HEAD BOLT 1
0040512000 TOOTHED WASHER 1
10 012210020 HEX. HEAD BOLT ........................... 1 ........... REPLACES 0017110020
0040510000 TOOTHED WASHER 1
DCA-100SSJU --- BATTERY ASSY.
BATTERY ASSY.
