ASSEMBLY INSTRUCTIONS/OPERATIONS
TWO SECTION DRUM ASSEMBLY
8FP FLOOR PLANER SERIES OPERATION AND PARTS MANUAL REV #1 (10/27/06) PAGE 67
TWO SECTION DRUM ASSY.
NO.
PART NO. PART NAME QTY. REMARKS
1# 29020-040 SHCSS, ¼”-20 X 1 8
2# 29020-041 FLAIL DRUM END CAP 2
3# 29020-042 FLAIL DRUM ROD 4
4# 07029-004 WASHER, LOCK 1/4 8
5# 08233-004 LOCKNUT 1/4-20” 8
6# 29020-043 FLAIL DRUM 2 SECTION 1
7# 29021-003 FLAIL DRUM, 1 SECTION COMPLETE......................1............ INCLUDES ITEMS W/#
