ASSEMBLY INSTRUCTIONS/OPERATIONS
DRIVESHAFT ASSEMBLY
8FP FLOOR PLANER SERIES OPERATION AND PARTS MANUAL REV #1 (10/27/06) PAGE 53
DRIVESHAFT ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 29020-011 RING, RETAINING EXTERNAL 2
2 29020-012 SHEAVE, DRIVESHAFT 1
3 29020-013 KEY, SPECIAL 1
4 29020-014 SHEAVE, CENTER HUB 1
5 06500-008 SCREW, CAP 5/16-18 NC X 1” PLATED GRADE 5 3
6 29020-015 DRIVESHAFT 1
7 29020-016 BEARING, SEALED, 5208-2RS 2
8 08233-006 NUT, HEX SELF-LOCKING 3/8-16 NC PLATED 8
9 29020-17 BLOCK, BEARING MOUNTING 2
10 29020-018 SHCS 3/8-16 X 1-3/8 8
11 06503-008 HHCS, 1/2” -13 X 1” 4
12 29020-019 PLATE, MAIN FRAME SIDE 1
13 29020-020 INSERT, HEX 1
14 29020-021 BUSHING, DOWEL 2
15 SP8-0560 FITTING, GREASE 90
° X 1/8” NPT
1
16 SP8-0570 90
° STREET ELBOW, 1/8” NPT X 1/8” NPT
1
17 SP8-0600 HOSE, GREASE 1
18 SP8-0590 FITTING, GREASE STRAIGHT 1/8” NPT 1
19 GP8-0090 SPACER 2
20 SP8-0440 HOSE MOUNT 1
21 SP8-4000 WASHER, HARDENED 4
