ASSEMBLY INSTRUCTIONS/OPERATIONS
GASOLINE ENGINE ASSEMBLY
8FP FLOOR PLANER SERIES OPERATION AND PARTS MANUAL REV #1 (10/27/06) PAGE 59
GASOLINE ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 29020-001 FRAME, MAIN 1
2 GX160KQXC9 ENGINE, HONDA 5.5HP 1
3 29020-037 DRIVE PULLEY 1
4 29020-038 BUSHING, CENTER HUB 1
5 06499-006 SCREW, CAP ¼” UNC X ¾” GRADE 5 2
6 10057-016 KEY, STANDARD 3/16” X 3/16” X 1-1/2” 1
7 29020-005 BRACKET, ENGINE MOUNT 2
8 06500-016 SCREW, CAP 5/16”-18 X 2 UNC X 2” PLATED GRADE 5 4
9 29020-006 BELT TENSIONING SCREW 2
10 CV0411 CLAMP, PLATED 2
11 06499-006 SCREW, CAP 1/4”-20 X 3/4” UNC PLATED GRADE 5 1
12 07030-005 WASHER, FLAT 5/16” PLATED 4
13 08233-005 NUT, HEXAGON 5/16” UNC SELF-LOCKING PLATED 6
14 07029-004 WASHER, LOCK ¼” PLATED 1
15 07033-004 NUT, HEXAGON 1/4”-20 UNC PLATED 1
16 SP8-0380 CAP, PLASTIC 2
17 29020-056 V-BELT, 3VX335 1
18 29020-039 BELT GUARD 1
19 07030-006 WASHER, FLAT 3/8” PLATED 3
20 08233-006 NUT, HEXAGON 3/8”-16 3
21 SP8-0400 ADAPTER 1
22 SP8-0390 HOSE, OIL DRAIN 1
23 SP8-6600490 CAP, FEMALE ¼” NPT 1
