ASSEMBLY INSTRUCTIONS/OPERATIONS
OPERATOR HANDLE ASSEMBLY (ELECTRIC)
8FP FLOOR PLANER SERIES OPERATION AND PARTS MANUAL REV #1 (10/27/06) PAGE 61
OPERATOR HANDLE ASSY (ELECTRIC)
NO. PART NO. PART NAME QTY. REMARKS
1 29020-028 HANDLE OPERATOR 1
2 29020-029 SCREW, CRANK 1
3 29020-031 KNOB, HANDLE 1
4 29020-031 HEIGHT ADJUSTMENT SCREW 1
5 06500-008 SCREW, CAP 5/16-18 NC X 1”,PLATED GRADE 5 2
6 29020-032 BEARING 1
7 29020-033 NUT 1
8 14821-004 CLAMP, HOSE 1-1/4” PLATED 1
9 29020-034 BOOT, RUBBER 1
10 29020-053 ADJUSTING TUBE SWITCH MOUNT 1
11 06922-004 NUT, HEX JAM 5/8” UNF LT HAND THREAD PLATED 1
12 29020-036 ROD END 1
13 08233-008 NUT, HEX 1/2 ”-13 4
14 06503-010 HHCS, 1/2” X 1-1/4” UNC PLATED GRADE 5 4
15 08233-005 NUT, HEX 5/16”-18 2
16 29018-039 HOUSING, SWITCH 1
17 29018-044 SWITCH, ON/OFF 1
18 29018-029 STRAIN RELIEF 3
19 29018-030 NUT, BULKHEAD 3
20 08885-013 PLUG, MALE 60HZ OPERATION ONLY 1
21 06499-004 SCREW, CAP ¼”-20” UNC X ½” PLATED 2
22 07029-004 WASHER, LOCK ¼” PLATED 2
23 07033-004 NUT, HEX ¼”-20” UNC PLATED 2
24 29018-041 CABLE, ELECTRICAL SHORT 12” 1
25 29020-054 CABLE, ELECTRICAL LONG 1
26 08885-014 RECEPTACLE, FEMALE 60 HZ OPERATION ONLY 1
27 07030-008 WASHER, FLAT ½” PLATED 4
