ASSEMBLY INSTRUCTIONS/OPERATIONS
MAIN FRAME ASSEMBLY
8FP FLOOR PLANER SERIES OPERATION AND PARTS MANUAL REV #1 (10/27/06) PAGE 51
MAIN FRAME ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 29020-001 FRAME, MAIN 1
2 29020-002 TUBE, VACUUM 1
3 SP8-0061 AXLE MOUNT 1
4 06503-010 SCREW, CAP ½-1-1/4” UNC PLATED GRADE 5 2
5 06503-012 SCREW, CAP ½-1-1/2” UNC PLATED GRADE 5 2
6 07030-008 WASHER, FLAT ½” PLATED 4
7 08233-008 NUT, HEXAGON ½” UNC SELF-LOCKING PLATED 4
8 29020-004 WHEEL, CASTER 2
9 07030-012 WASHER, FLAT ¾” PLATED 2
10 07028-057 PIN, COTTER 5/32” X 1-1/2” PLATED 2
11 07029-004 WASHER, LOCK ¼” PLATED 4
12 06499-006 SCREW, CAP ¼”X ¾” UNC PLATED GRADE 5 4
13 29020-010 CAP, DUST COVER 1
14 29020-009 PLUG, PIPE ¼” NPTF SQUARE 1
15 29020-008 FITTING, REDUCING, DO NOT USE................................. 1.........OPTION
16 29020-007 VALVE DO NOT ................................................................. 1.........OPTION
17 SP8-0370 AXLE 1
18 06501-012 HHCS, 3/8”-16 X 1-1/2” UNC PLATED GRADE 5 2
19 07029-006 WASHER, LOCK 3/8” PLATED 2
20 07033-006 LOCKNUT, HEXAGON 3/8”-16 UNC PLATED 2
21 CS8-0900 HOSE, JUMPER ................................................................. 1.........OPTION
