ASSEMBLY INSTRUCTIONS/OPERATIONS
ONE SECTION DRUM ASSEMBLY
8FP FLOOR PLANER SERIES OPERATION AND PARTS MANUAL REV #1 (10/27/06) PAGE 65
ONE SECTION DRUM ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1# 29020-040 SHCSS, ¼”-20 X 1 8
2# 29020-041 FLAIL DRUM END CAP 2
3# 29020-042 FLAIL DRUM ROD 4
4# 07029-004 WASHER, LOCK 1/4 8
5# 08233-004 LOCKNUT 1/4-20” 8
6# 29020-044 SUPPORT STRAP 4
7# 29020-045 FLAIL DRUM 1 SECTION 1
8 29021-002 FLAIL DRUM, 1 SECTION COMPLETE......................1............ INCLUDES ITEMS W/#
