HTXD6i/STXD6i TROWEL • SETUP, ADJUSTMENTS AND CALIBRATIONS — REV. #1 (01/24/14) — PAGE 29
STATIC BLADE PITCH DRIFT TEST
1. Switch smart pitch switch to off position.
2. Bring machine up to temperature. This will be indicated
by “Cold Start” (aux 1) lamp turning off.
3. Choose one blade from each spider and mark with
small X to identify.
4. Using the Twin pitch button, cycle the blades from flat
to full pitch 8 times leaving the blades in the full pitch
position on the eighth cycle.
5. Turn the engine off, and record time and tip height on
Machine Information and Maintenance Log.
6. Leave for a 3-hour test period then re-measure tip
height. Record height and time on Machine Information
and Maintenance Log.
7. Compare the two measurements. Drift exceeding 3/16”
in three hours is unacceptable.
INSPECTION
