PAGE 24 — PRO12 HYDRAULIC MIXER • OPERATION MANUAL — REV. #1 (06/04/14)
7. Turn the engine ignition key (Figure 18) to the START
position and hold it until the engine starts. When engine
starts, release the key, allowing it to return to the ON
position.
Figure 18. Engine Ignition Key
8. If the choke lever was moved to the " CLOSED" position
to start the engine gradually move it to the "OPEN"
position (Figure 19) as the engine warms up. If the
engine has not started repeat steps 1 through 6.
Figure 19. Choke Lever (Open)
9. Before the mixer is placed in to operation, run the
engine for several minutes. Check for fuel leaks, and
noises that would associate with a lose component.
10. To begin mixing, place the throttle lever (Figure 20) in
the “ RUN” position .
Figure 20. Throttle Lever (Run)
OFF O
N
S
T
A
R
T
STOPPING THE ENGINE
Normal Shutdown
1. Move the throttle lever to the IDLE position (Figure 21)
and run the engine for three minutes at low speed.
Figure 21. Throttle Lever (Idle)
2. After the engine cools, push the Start/Stop switch
on the engine cover inward to the “ OFF” position
(Figure 22).
Figure 22. Start/Stop Switch (OFF Position)
3. Place the fuel shut-off lever (Figure 23) in the " OFF"
position.
Figure 23. Fuel Valve Lever (OFF)
Emergency Shutdown
1. Move the throttle lever quickly to the IDLE position, and
place the engine ON/OFF switch in the OFF position.
START/STOP
SWITCH
PUSH IN
TO STOP
STARTUP (GASOLINE ENGINE)
