Paddle blade adjustment, Steel drum – Multiquip PRO12E53 User Manual
Page 20
PAGE 20 — PRO12 HYDRAULIC MIXER • OPERATION MANUAL — REV. #1 (06/04/14)
PADDLE BLADE ADJUSTMENT
CAST PADDLE
ENGINE END
CAST PADDLE
CENTER ENGINE
END CAST PADDLE
SIDE PADDLE BLADE
END P
ADDLE BLADE
ROTATION
RO
T
A
TION
PADDLE BLADE IS TOO
TIGHT AGAINST DRUM
SIDE WALLS.
PADDLE BLADE IS TOO
TIGHT AGAINST DRUM
SIDE WALLS.
DRUM END AND SIDE WALLS
CENTER TOW END
CAST PADDLE
STEEL DRUM
INCORRECT
INCORRECT
CORRECT
CORRECT
INCORRECT
DRUM END
DRUM SIDE
Figure 6. Paddle Blade Adjustment
