PRO12 HYDRAULIC MIXER • OPERATION MANUAL — REV. #1 (06/04/14) — PAGE 21
INSPECTION
BEFORE STARTING
1. Read safety instructions at the
beginning of manual.
2. Clean the mixer, removing dirt and
dust, particularly the engine cooling
air inlet, carburetor and air cleaner.
3. Check the air filter for dirt and dust. If air filter is dirty,
replace air filter with a new one as required.
4. Check carburetor for external dirt and dust. Clean with
dry compressed air.
5. Check fastening nuts and bolts for tightness.
ENGINE OIL CHECK
1. To check the engine oil level, place the mixer on secure
level ground with the engine stopped.
2. Remove the filler dipstick from the engine oil filler hole
(Figure 7) and wipe clean.
Figure 7. Engine Oil Dipstick (Removal)
3. Insert and remove the dipstick without screwing it into
the filler neck. Check the oil level shown on the dipstick.
4. If the oil level is low (See Figure 8), fill to the edge of
the oil filler hole with the recommended oil type
as listed in Table 6. Maximum oil capacity is 1.16
quarts(1.1 liters).
Figure 8. Engine Oil Dipstick (Oil Level)
FUEL CHECK
1. Remove the gasoline cap located on top of fuel tank.
2. Visually inspect to see if the fuel level is low. If fuel is
low, replenish with unleaded fuel .
3. When refueling, be sure to use a strainer for filtration.
DO NOT top-off fuel. Wipe up any spilled fuel
immediately!
START/STOP SWITCH CHECK
This switch should be tested every time the engine is
started.
Table 6. Oil Type
Season Temperature Oil Type
Summer 25°C or Higher SAE 10W-30
Spring/Fall 25°C~10°C SAE 10W-30/20
Winter 0°C or Lower SAE 10W-10
DANGER
Motor fuels are highly flammable and can
be dangerous if mishandled. DO NOT
smoke while refueling. DO NOT attempt
to refuel the pump if the engine is hot!
or running.
CAUTION
NEVER disable or disconnect the start/stop switch. It
is provided for operator safety. Injury may result if it is
disabled, disconnected or improperly maintained.
