PRO12 HYDRAULIC MIXER • OPERATION MANUAL — REV. #1 (06/04/14) — PAGE 11
SPECIFICATIONS
Table 1. Mixer Specifications
Capacity 12.0 cu. ft (340 liters)
Bag Capacity 3 to 4 bags
Operating Weight 1580 lbs. (716.68 kg.)
Maximum Aggregate Size 1 in. (25.4 mm)
Adjustable Drum Discharge Height Up to 42.5 in. (1079.5 mm.)
Drive System Hydraulic
Dump Action Hydraulic
Table 2. Engine Specifications
Model Honda GX390RT2-QNB2
Type Air-cooled 4 stroke, Horizontal Shaft, Gasoline Engine
Bore X Stroke
3.46 in. X 2.51 in.
(88 mm x 64 mm)
Displacement 23.7 cu. in. (389 cc)
Max Output 11.7 H.P./3600 R.P.M.
Continuous Output 9.0H.P./3600 R.P.M.
Fuel Tank Capacity Approx. 1.7 U.S. Gallons (6.5 Liters)
Fuel Unleaded Gasoline
Lube Oil Capacity 1.16 qt. (1.1 liter)
Speed Control Method Centrifugal Fly-weight Type
Starting Method Electric Start
Table 3. Electric Motor Specifications
Model Teco Westinghouse Model 3415 Teco Westinghouse Model 3481
Enclosure TEFC TEFC
Horsepower 5 5
Input Voltage (VAC) 230 230/460
Phase 1 3
Frequency (Hz) 60 60
Max Output@RPM 5 HP@1745 5 HP@1725
Full Load Amps 30 12.24/6.12
Weight 103 lbs (46.7 kg) 103 lbs (46.7 kg)
Dimensions (LxWxH)
18.03 x 8.8 x 10.5 in
(458 x 223.5 x 266.7 mm)
15.79 x 8.8 x 10.5 in
(401 x 223.5 x 266.7 mm)
