ga6HB/6HeB 60 hz gENERATOR • OpERATiON ANd pARTs mANuAl — REv. #0 (03/13/14) — pAgE 33
GeneRaToR wiRinG DiGRam (Ga6Heb)
Ar
Fg-P, N
Ex W1
ARMATURE WINDING
ROTOR ASSEMBLY
EXCITATION WINDING
EXCITATION WINDING
CON 1 RECEPTACLE L5-20R 20A, 125V
CON 2 RECEPTACLE L5-30R 30A 125V
CON 3 RECEPTACLE L14-30R 30A, 125/250V
FULL POWER SWITCH SW1
IDLE CONTROL SWITCH SW2
OPERATION SWITCH SW3
IDLE CONTROL DEVICE RC
IDLE CONTROL SOLENOID S
CAPACITOR C
CON 4,5 RECEPTACLE 5-20R GFCI 20A, 125V
Ex W2
CIRCUIT BREAKER 23A CB
AC VOLTMETER 120/240V
V
~
RECTIFER RE 1~2
STARTER SWITCH SW4
22 GFCI SENSING MODULE
TERMINAL BOARD
SYMBOL DESIGNATION
CONNECTOR ARRANGEMENT
(VIEW FROM INSERTING WIRE SIDE)
2 1
4 3
W R
CN1 CN2
CN5 CN4
CN3
B
L
G
V
P
R
W
Y
O
BR
GR
LB
LG
WIRE COLOR
BLACK
BLUE
BROWN
GREEN
GRAY
VIOLET
PINK
ORANGE
LIGHT GREEN
LIGHT BLUE
YELLOW
WHITE
RED
WIRE COLOR
COLOR CODE
GENERATOR
ENGINE
B C
A J
K
1
2
1 2
4 6
3
CN6 CN7
K C
J A
B
5
3 2
6 4
1
5
Figure 43. Generator Wiring Diagram (GA6HEB)
