MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 71
HONDA GX160K1QMX2/GX160U1QMX2 ENG. — PISTON ASSY.
NOTICE
4 GX160K1QMX2: Model MVC-90H S/N N-5696 AND BELOW
¡ GX160U1QMX2: Model MVC-90H S/N N-5697 AND ABOVE
PISTON ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1
4
13010ZF1023 RING SET, PISTON (STD) .................................1................S/N 5495899 AND BELOW
1
4
13010ZH8941 RING SET, PISTON (STD) .................................1................S/N 5495900~7603338
1
4
13010ZL0003 RING SET, PISTON (STD) .................................1................S/N 7603339 AND ABOVE
1 ¡ 13010ZL0003 RING SET, PISTON (STD) 1
1
4
13011ZF1023 RING SET, PISTON (OS 0.25) ...........................1................S/N 5495899 AND BELOW
1
4
13011ZH8941 RING SET, PISTON (OS 0.25) ...........................1................S/N 5495900~7603338
1
4
13011ZL0003 RING SET, PISTON (OS 0.25) ...........................1................S/N 7603339 AND ABOVE
1 ¡ 13011ZL0003 RING SET, PISTON (OS 0.25) 1
1
4
13012ZF1023 RING SET, PISTON (OS 0.50) ...........................1................S/N 5495899 AND BELOW
1
4
13012ZH8941 RING SET, PISTON (OS 0.50) ...........................1................S/N 5495900~7603338
1
4
13012ZL0003 RING SET, PISTON (OS 0.50) ...........................1................S/N 7603339 AND ABOVE
1
4
13013ZF1023 RING SET, PISTON (OS 0.75) ...........................1................S/N 5495899 AND BELOW
1
4
13013ZH8941 RING SET, PISTON (OS 0.75) ...........................1................S/N 5495900~7603338
1
4
13013ZL0003 RING SET, PISTON (OS 0.75) ...........................1................S/N 7603339 AND ABOVE
1 ¡ 13013ZL0003 RING SET, PISTON (OS 0.75) 1
2
4
13101ZH8000 PISTON (STD) ...................................................1................S/N 7603338 AND BELOW
2
4
13101ZH8010 PISTON (STD) ...................................................1................S/N 7603339 AND ABOVE
2 ¡ 13101ZH8010 PISTON (STD) 1
2
4
13102ZH8000 PISTON (OS 0.25) ............................................1................S/N 7603338 AND BELOW
2
4
13102ZH8010 PISTON (OS 0.25) ............................................1................S/N 7603339 AND ABOVE
2 ¡ 13102ZH8010 PISTON (OS 0.25) 1
2
4
13103ZH8000 PISTON (OS 0.50) ............................................1................S/N 7603338 AND BELOW
2
4
13103ZH8010 PISTON (OS 0.50) ............................................1................S/N 7603339 AND ABOVE
2 ¡ 13103ZH8010 PISTON (OS 0.50) 1
2
4
13104ZH8000 PISTON (0.75) ..................................................1................S/N 7603338 AND BELOW
2
4
13104ZH8010 PISTON (0.75) ..................................................1................S/N 7603339 AND ABOVE
2 ¡ 13104ZH8010 PISTON (0.75) 1
3 13111ZE1000 PIN, PISTON 1
4 13200ZE1010 ROD ASSY., CONNECTING ..............................1................INCLUDES ITEM W/@
5@ 90001ZE1000 BOLT, CONNECTING ROD 2
6 90551ZE1000 CLIP, PISTON PIN (18MM) 2
