MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 23
MVC-90H PLATE COMPACTOR — MAINTENANCE
Engine Oil Replacement:
1. Replace engine oil, in first 20 hours of operation and
every 100 hours afterwards.
2. Oil may be drained more easily when it is warm after
operation (For more details, see separate engine Owner's
Manual).
3. When changing the engine oil, thenold oil can be drained
by removing the oil filler cap, and un-screwing the engine
oil drain plug located at the base of the engine
(Figure 19).
4. Remember to refill engine crankcase with the
recommended type of oil as listed in Table 4.
Figure 19. Engine Oil Plug
Figure 20. Air Filter
Air Filter
1. The air filter element should be cleaned because a
clogged air cleaner can cause poor engine starting, lack
of power and shorten engine life substantially.
2. To clean or replace air filter loosen the wing nut on the
air filter housing (Figure 20), remove the cover and take
out air filter cartridge.
If only cleaning of the air filter is desired blow through
the air filter cartridge from the inside, moving a jet of
dry compressed air up and down until all dust is removed.
Changing Vibrator Oil
1. When changing the vibrator oil, remove the oil plug
located at the bottom of the vibrator (Figure 19),
2. Tip the compactor to drain the oil.
Vibrator oil will drain more easily
while it is warm. NOTE
