MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 17
MVC-90H PLATE COMPACTOR — INSPECTION
3. Insert and remove the dipstick without screwing it into
the filler neck. Check the oil level shown on the dipstick.
4. If the oil level is low (Figure 6), fill to the edge of the oil
filler hole with the recommended oil type (Table 4).
Maximum oil capacity is 400 cc.
Figure 6. Engine Oil Dipstick
e
p
y
T
li
O
.
4
e
l
b
a
T
n
o
s
a
e
S
e
r
u
t
a
r
e
p
m
e
T
e
p
y
T
li
O
r
e
m
m
u
S
r
e
h
g
i
H
r
o
C
°
5
2
0
3
-
W
0
1
E
A
S
ll
a
F
/
g
n
ir
p
S
C
°
0
1
~
C
°
5
2
0
2
/
0
3
-
W
0
1
E
A
S
r
e
t
n
i
W
r
e
w
o
L
r
o
C
°
0
0
1
-
W
0
1
E
A
S
The Oil Alert system will
automatically stop the engine
before the engine falls below
safe limits. Always be sure to
check the engine oil level prior
to starting the engine.
NOTE
CAUTION - General Safety Precautions
ALWAYS wear approved eye and hearing
protection before operating the
compactor.
NEVER operate the compactor in a
confined area or enclosed area structure
that does not provide ample
free flow of
air.
Before Starting:
Figure 5. Engine Oil Dipstick
■ Read safety instructions at the
beginning of manual.
■ Remove dirt and dust, particularly
in the engine cooling air inlet,
carburetor and air cleaner.
■ Check the air filter for dirt and dust. If air filter is dirty,
clean or replace the air filter with a new one as required.
■ Check carburetor for external dirt and dust. Clean with
dry compressed air.
■ Check fastening nuts and bolts for tightness.
■ Check the Engine Oil level.
■ Check the Fuel level.
■ Check the V-belt tension and wear.
■ Check the Vibrator Oil level.
Engine Oil Check
1. To check the engine oil level, place the plate compactor
on secure level ground with the engine stopped.
2. Remove the filler cap/dipstick from the engine oil filler
hole (Figure 5) and wipe it clean.
