MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 53
HONDA GX160K1QMX2/GX160U1QMX2 ENG. — CRANKCASE COVER ASSY.
NOTICE
4 GX160K1QMX2: Model MVC-90H S/N N-5696 AND BELOW
¡ GX160U1QMX2: Model MVC-90H S/N N-5697 AND ABOVE
CRANKCASE COVER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1
4
11300ZE1641 COVER ASSY., CRANKCASE (U-TYPE) ..........1................INCLUDES ITEMS W/@
1 ¡ 11300ZE1642 COVER ASSY., CRANKCASE (U-TYPE) ..........1................INCLUDES ITEMS W/%
3 11381ZH8801 GASKET, CASE COVER 1
4 15600ZE1003 CAP ASSY., OIL FILLER ....................................1................INCLUDES ITEMS W/#
5 15600ZG4003 CAP ASSY., OIL FILLER ....................................1................INCLUDES ITEMS W/+
6# 15620ZE1003 CAP, OIL FILLER
9# 15625ZE1003 GASKET, OIL FILLER CAP 1
10+ 15625ZE1003 GASKET, OIL FILLER CAP 1
11
4@ 91202883005
OIL SEAL (25 X 41 X 6) 1
11 ¡% 91201Z0T801 OIL SEAL (25 X 41 X 6) 1
12 9430108140 PIN A, DOWEL (8 X 14) 2
13 957010803200 BOLT, FLANGE (8 X 32) 6
14@% 961006205000 BEARING, RADIAL BALL (6205) 1
