MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 61
HONDA GX160K1QMX2/GX160U1QMX2 ENG. — FAN COVER ASSY.
NOTICE
4 GX160K1QMX2: Model MVC-90H S/N N-5696 AND BELOW
¡ GX160U1QMX2: Model MVC-90H S/N N-5697 AND ABOVE
FAN COVER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 19610ZE1000ZC COVER, FAN *NH1* (BLACK) 1
4 19612ZH8811 PLATE, SIDE (OIL ALERT) 1
5 ¡ 36101ZE1010 CORD, STOP SWITCH 370 MM 1
7 90601ZH7013 CLIP, HARNESS 1
8 19630ZH8000 SHROUD 1
11
4
36100ZE1015 SWITCH ASSY., ENGINE STOP .......................1................S/N 4368640 AND BELOW
11
4
36100ZH7003 SWITCH ASSY., ENGINE STOP .......................1................S/N 4368641 AND ABOVE
11 ¡ 36100ZF6P81 SWITCH ASSY., ENGINE STOP 1
13 90013883000 BOLT, FLANGE (6 X 12) (CT200) 6
14 90022888010 BOLT, FLANGE (6 X 20) (CT200) 1
17 34150ZH7003 ALERT UNIT, OIL 1
19 957010600800 BOLT, FLANGE (6 X 8) 1
