MVC-90H PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #3 (01/10/11)— PAGE 49
HONDA GX160K1QMX2/GX160U1QMX2 ENG. — CARBURETOR ASSY.
NOTICE
4 GX160K1QMX2: Model MVC-90H S/N N-5696 AND BELOW
¡ GX160U1QMX2: Model MVC-90H S/N N-5697 AND ABOVE
CARBURETOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16010ZE1812 GASKET SET 1
2@ 16011ZE0005 VALVE SET, FLOAT 1
3@ 16013ZE0005 FLOAT SET 1
4@ 16015ZE0831 CHAMBER SET, FLOAT 1
5@ 16016ZH7W01 SCREW SET 1
6@ 16024ZE1811 SCREW SET, DRAIN 1
7@ 16028ZE0005 SCREW SET B 1
8@ 16044ZE0005 CHOKE SET 1
9@ 16100ZH8W51 CARBURETOR ASSY. (BE65B B) .....................1................INCLUDES ITEMS W/@
10@ 16124ZE0005 SCREW, THROTTLE STOP 1
11@ 16166ZH8W50 NOZZLE, MAIN 1
12@ 16173001004 O-RING 1
13 16211ZE1000 INSULATOR, CARBURETOR 1
14 16212ZH8800 GASKET, INSULATOR 1
15 16220ZE1020 SPACER, CARBURETOR 1
16 16221ZH8801 GASKET, CARBURETOR 1
17 16610ZE1000 LEVER, CHOKE (STD) ......................................1................INCLUDES ITEMS W/#
18@ 16953ZE1812 LEVER, VALVE 1
19@ 16954ZE1811 PLATE, LEVER SETTING 1
19@ 16954ZE1812 PLATE, LEVER SETTING 1
20@ 16956ZE1811 SPRING, VALVE LEVER 1
21@ 16957ZE1812 GASKET, VALVE 1
22@ 16967ZE0811 CUP, FUEL STRAINER 1
23@ 93500030060H SCREW, PAN (3 X 6) 2
23@ 93500030061H SCREW, PAN (3 X 6) 2
24# 9430520122 PIN, SPRING (2 X 12) 1
25
4 99101ZH80650 JET, MAIN (#65) OPTIONAL
1
25
4 99101ZH80680 JET, MAIN (#68) OPTIONAL
1
25@ 99101ZH80700 JET, MAIN (#70) 1
26@ 99204ZE00350 JET, SET, PILOT (#35) 1
