MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 43
NO. PART NO. PART NAME QTY. REMARKS
10 1615110701 FAN COVER ................................. 1 ............................. REPLACES 1615110706
40 0011406200 BOLT AND WASHER ASSY 3
41 0011406550 BOLT AND WASHER ASSY 2
50 1615260203 CYLINDER BAFFLE 1
70 1619186003 LABEL(ENGINE NAME) 1
80 0110060020 FLANGE BOLT 3
81 0152060070 TAPPING BOLT 3
210 1615010400 RECOIL STARTER ASSY ............ 1 ............................. INCLUDES ITEMS W/ *
210-1 * 2155051508 SPIRAL SPRING 1
210-2 * 1615012008 REEL 1
210-3 * 1615011008 STARTER ROPE 1
210-4 * 2365010108 STARTER KNOB 1
210-5 * 1615012508 RATCHET 2
210-6 ** 2275013108 FRICTION SPRING 1
210-7 * 2275013508 RETURN SPRING 2
210-11 * 1615014518 STARTER PULLEY 1
210-35 * 1615015008 RATCHET GUIDE 1
210-49 * 2275015208 SET SCREW 1
216 920100240 DECAL, (M-MARK) 1
220 0011406120 BOLT AND WASHER ASSY ......... 4 ............................. REPLACES 0011306120
230 0011306250 BOLT AND WASHER ASSY 3
231 2267510103 CLAMP 1
240 1615500113 PULLEY SPACER 1
ROBIN EC12HS ENGINE — RECOIL STARTER ASSY.
