MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 33
NO. PART NO. PART NAME QTY. REMARKS
1 0 1611040301 CRANK CASE CP ................................ 1 ............INCLUDES ITEMS W/ *
30
*
0440250180 OIL SEAL EC13 2
36
*
0440080010 OIL SEAL VC 8X14X4 1
40
*
0600250010 BALL BEARING 6205C3 1
50
*
0310060010 DOWEL PIN 2
60
*
# 0013208351 STUD 2
70
*
# 0105060070 STUD 2
82
*
0241060010 GROMMET 1
95
*
0011406550 BOLT AND WASHER ASSY 3
96
*
0011406400 BOLT AND WASHER ASSY 2
115
*
0013208401 STUD 2
116
*
0013208651 STUD 2
140 0643000101 DRAIN COCK 1
180 0021708000 NUT ...................................................... 4 ............REPLACES 0021808000
190 030208200 WASHER .............................................. 4 ............REPLACES 0032008000
200 0031008000 WASHER 4
510 1611240311 CYLINDER CP ..................................... 1 ............INCLUDES ITEMS W/# REPLACES 1611240301
610 1571310113 CYLINDER HEAD 1
620 1611510101 GASKET COMPL.(HEAD) ................... 1 ............REPLACES 161151011
630 0130080071 BOLT AND WASHER ASSY 2
631 0011408350 BOLT AND WASHER ASSY 2
ROBIN EC12HS ENGINE — CRANKCASE ASSY.
