MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 25
NO. PART NO. PART NAME QTY. REMARKS
1 354111690 CRANK CASE 1
2 352321580 CRANK GEAR 1
3 040006207 BEARING 6207 1
4 040006305 BEARING 6305 1
5 952400690 WASHER 9X35X4.5 ............................. 1 ............REPLACES 031108160
6 002210825 BOLT 8X25 H, SW ............................... 1 ............REPLACES 011708025
8 352423271 BEARING COVER 1
9 050920630 O-RING JASO2063 1
10 002210620 BOLT 6X20 H,SW ................................ 4 ............REPLACES 011706020
16 301300530 CONNECTING ROD 1
17 040006305 BEARING 6305 1
18 080100620 STOP RING R-62 1
19 952400690 WASHER 9X35X4.5 ............................. 1 ............REPLACES 031108160
20 002210825 BOLT 8X25 H, SW ............................... 1 ............REPLACES 011708025
25 354213480 FRONT COVER 1
26 354444460 PACKING, FRONT COVER 1
27 002210620 BOLT 6X20 H,SW ................................ 10 ..........REPLACES 011706020
29 352437870 CLUTCH DRUM 1
30 951405500 KEY 5X5X28 R 1
31 952405490 LOCK WASHER 1
32 002210820 BOLT 8X20 H, SW 1
33 041006207 BEARING 6207Z 1
34 040006205 BEARING 6205 .................................... 1 ............REPLACES 0600250010
35 080200350 STOP RING S-35 1
36 301010160 PINION 1
37 352441340 SPACER 1
38 060404010 OIL SEAL TC-40528 1
39 050100950 O-RING G-95 1
43 911101213 ENGINE ASSY EC12 ........................... 1 ............REPLACES 911101211
44 301421363 CLUTCH ASSY C812E ........................ 1 ............INCLS. PARTS W/ *
44-1 * 943060020 CLUTCH GUIDE/B 1
44-2 * 943050050 CLUTCH BOSS C812 1
44-3 * 943020020 CLUTCH SHOE C812 4
44-4 * 943030020 CLUTCH SPRING C812 2
44-5 * 943060010 CLUTCH GUIDE /A IT 1
45 0053204201 WOODRUFF KEY 1
46 * 301010210 LOCK WASHER CLUTCH 1
47 956300130 THROTTLE LEVER ASSY 1
48 956106040 THROTTLE WIRE 1
49 301010950 RETURN SPRING ............................... 1 ............REPLACES 402010110
50 959403750 RUBBER, SLIP STOP 1
52 002211045 BOLT 10X45 H,SW .............................. 2 ............REPLACES 012710045
53 002211035 BOLT 10X35 H,SW .............................. 1 ............REPLACES 012710035
61 354211841 AIR CLEANER ASSY ........................... 1 ............INCLS. ALL ITEMS W/#
62 002200820 BOLT 8X20 SW .................................... 4 ............REPLACES 011008020
63 354330590 INTAKE PIPE 1
64 507010110 CLAMP TC-200 1
65# 354030011 BODY/W-CLEANER 1
66# 354030020 BACK PLATE 1
67# 354030030 ELEMENT, YELLOW 1
68# 354030040 ELEMENT, GRAY 1
69# 354030050 ELEMENT FRAME 1
70 002200815 BOLT 8X15 SW 1
71 0566000170 CLAMP 1
72 002171400 NUT 1
CRANKCASE AND ENGINE ASSY.
