MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 29
NO. PART NO. PART NAME QTY. REMARKS
A 353213710CPL OIL TANK ASSY W/CAP ......................... 1 ................ REPLACES 353910030
1 355115020 HANDLE (ROLLER) 1
2 351319900 SHOCK ABSORBER 100D-45B 2 ................ REPLACES 355113570
3 001521020 SOCKET HEAD BOLT 10 x 20 4
4 033121009 TOOTHED LOCK WASHER B M10 4
5 002211020 BOLT 10 x 20 H, SW 4
6 355113610 FUEL TANK 1
7 954404890 FILTER, TANK 1
8 361910020 TANK CAP ASSY (ORANGE) 1
9 954405990 FUEL COCK ASSY CVL-1 1 ................ INCLUDES ITEMS W/#
9-1# 0642001410 BOWL FUEL FILTER 1
9-2# 0642001420 STRAINER SCREEN 1
9-3# 0642001430 PACKING 1
10 351436350 FUEL HOSE R-150 1
11 954404590 HOSE BAND 9.50D 2
12 001220830 BOLT 8 x 30 T 2
13 301418140 FUEL HOSE B-150 1
14 301419750 FUEL FILTER CP, MQ75MIC 1
15 954403030 HOSE BAND (8) 2
16 303010450 BAND 1
17 030208200 WASHER, SW M8 2
18 952401450 WASHER 8. 5 x 22 x 3 2
19 022710809 NYLON NET M8 2
20 351437785 HOLDER, COCK 1
21 953405640 PACKING, COCK HOLDER 1
21 9544S06020 PACKING, FUEL TANK 1
22 954405080 STRAINER (#100) 1
22 954406010 STRAINER (#110) 1
31 * OIL TANK 1 ................ * MUST ORDER NEW OIL TANK ASSY
31-1 353213710 OIL TANK 1
32 * OIL TANK CAP 1
32-1 353030070 OIL TANK CAP CP (YELLOW) 1
35 STRAINER, OIL TANK 1 ................ NO LONGER USED
36 355448071 COVER, COCK HOLDER 1 ................ REPLACES 355448070
37 009110011 SOCKET HEAD SCREW 8 x 20 2
38 030208200 WASHER, SW M8 2
39 952401450 WASHER 8.5 x 22 x 3 2
40 001200610 BOLT 6 x 10 1
41 030206150 WASHER, SW M6 1
42 2267510103 CLAMP 1
45 355448280 WIRE CP 1
47 1616391308 HOSE 1
53 353448990 PACKING, OIL TANK CAP 1
54 353449001 STRAINER, OIL TANK 1 ................ REPLACES 353449000
TANK AND HANDLE ASSY.
