MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 27
NO. PART NO. PART NAME QTY. REMARKS
61 352423290 PISTON PIN 1
62 080100150 STOP RING R-15 2
63 352210380 PISTON ROD 1
64 352437330 PISTON END 1
65 020118150 NUT M18, P1.5 1
66 352431430 STOPPER, UPPER 1
67 352437470 STOPPER,LOWER 1
68 352326610 MAIN SPRING 2
69 354212480 SPRING CYLINDER (L) 1
70 352210401 FOOT PLATE 1
71 352110042 PROTECTION SLEEVE (L) 1
73 050100950 O-RING G-95 1
74 050101100 O-RING G-110 1
75 001521020 SOCKET HEAD BOLT 10X20 T .... 4 ................ REPLACES 014210020
76 001521035 SOCKET HEAD BOLT 10X35 T .... 4 ................ REPLACES 014210035
77 953405270 PLUG 1/4X14 13L 2
78 953405260 PACKING 1/4 (CU) 2
80 354446170 PIN 6D-8.5L 2
82 354212490 GUIDE CYLINDER (L) 1
86 354332700 BELLOWS(L) ORANGE 1
87 050931500 O-RING JASO3150 2
88-1 354910020 BELLOWS CLAMP CP .................. 2 ................ INCLUDES ITEMS W/ *
89 002211035 BOLT 10X35 H,SW ........................ 4 ................ REPLACES 012710035
90 959010150 LEVEL GUAGE, PLUG TYPE 1
91 953404670 COPPER PACKING 17X25.5X1 1
92 050201500 O-RING P-150 1
100 352910081 FOOT ASSY 330W-W/F.COVER .. 1 ................ INCL'S ITEMS W/# 13" (W) X 13" (L)
100 FOOT ASSY 285W-E/F COVER ... 1 ................ OPTION INCLS. ITEMS W/+ CONTACT
UNIT SALES DEPT./ACCESSORY ITEM
101+ 352108220 FOOT 285B-331L ......................... 1 ................ OPTION
101# 352326620 FOOT 330B-331L 1
102+ 352108230 METAL SHEET 285W ................... 1 ................ OPTION
102# 362326630 METAL SHEET 330B 1
103 001611259 SUNK HEAD BOLT 12X90 H ........ 2 ................ REPLACES 015112075 & 001611256
........................................................................... INCLUDES ITEMS W/%
104 001611260 SUNK HEAD BOLT 12X100 H ...... 2 ................ INCLUDES ITEMS W/ %
105#+ 015110055 SUNK HEAD BOLT 10X55 H ........ 7 ................ REPLACES 001611051
........................................................................... INCLUDES ITEMS W/$
106 022711214 NYLON NUT M12 .......................... 4 ................ REPLACES 021112140
107 030212300 WASHER SW M12 4
108#+ 022711012 NYLON NUT M10 .......................... 7 ................ REPLACES 021110120
109#+ 030210250 WASHER SW M10 7
113-1#+ 354332070 FOOT COVER 1
114 352441730 SPRING SEAT 80D-1.6T 1
115 * 354329380 BELLOWS CLAMP 2
116 * 354442340 BAND GUIDE, BELLOWS 2
117 * 001210835 BOLT 8X35 H ................................. 2 ................ REPLACES 011008035
118 * 020308060 NUT M8 .......................................... 2 ................ REPLACES 020108060
GUIDE CYLINDER AND FOOT ASSY.
