Multiquip MT85HS - Manual (Page 31)

MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 31
NO. PART NO. PART NAME QTY. REMARKS
55 353449010 STRAP, OIL TANK 2
58 353030080 WELL NUT M5 1
59 091005015 SCREW 5 x 15 1
60 031105080 WASHER, PW M5 1
60 952405970 WASHER 6.4D-20D 1
62 353449240 OUTER HOSE 6 x 9 x 65 1
62-1 353450220 GUARD, OIL HOSE 1
63 954403030 HOSE, BAND 1
64 1616391008 CLIP 1
65 1616391608 CLIP 1
66 1616391508 JOINT 1
67 353910020 OIL SENSOR ASSY 1
68 355450600 OUTER LINER 525L 1
69 361910040 ROLLER ASSY. W/PIN ............................ 2 ................ REPLACES 955200051
70 091005025 SCREW 5 x 25 4
71 031105080 WASHER, PW M5 4
72 022610505 FLANGE NUT M5 H 4
TANK AND HANDLE ASSY.
