MT85HS RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (01/16/12) — PAGE 37
GOVERNOR ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
10
1614230113
GOVERNOR LEVER
1
20
1064220103
GOVERNOR SHAFT
1
30
2274270101
GOVERNOR ROD
1
40
1064280113
ROD SPRING
1
80
1614250113
GOVERNOR SPRING
1
90
1574210103
GOVERNOR YOKE
1
100
0043504060
SCREW
2
110
1064240101
ADJUSTING PLATE 88 ....................... 1 ............REPLACES 1574240103
120
0021906000
NUT
1
130
030206150
SPRING WASHER ............................... 1 ............REPLACES 0032006000
140
0043504080
SCREW AND WASHER ASSY ............ 1 ............REPLACES 0043604080
310
1614341001
SPEED CONTROL CP ........................ 1 ............REPLACES 1614341011
311
1574510101
COVER
1
312
1574610103
WASHER
1
313
0110060020
FLANGE BOLT
1
360
0043106350
SCREW
1
370
0021706000
NUT
1
390
1614420113
WIRE BRACKET
1
420
0110060020
FLANGE BOLT
1
440
0115040010
BOLT
1
460
1614350111
STOP PLATE COMP ........................... 1 ............REPLACES 1614350121
461
0110060020
FLANGE BOLT
1
ROBIN EC12HS ENGINE — GOVERNOR ASSY.
