MTS Model 493-04 PC-Per-Station Kit User Manual
Page 14
MTS Model 493.04 PC-Per-Station-Kit
Configure PC network connections
14
A. In the Local Area Connection Properties window, select Internet
Protocol (TCP/IP), and click Properties.
B. In the Internet Protocol (TCP/IP) Properties window, enter the IP
address for the network connection. (See the following table for IP
addresses.)
Network Adapter IP Addresses
PC
C
ONTROLLER
N
ETWORK
G
ENERAL
D
ATA
N
ETWORK
*
IP
A
DDRESS
S
UBNET
M
ASK
IP A
DDRESS
S
UBNET
M
ASK
Master PC
148.150.203.190
255.255.255.0
10.0.0.1
255.255.255.0
Dependent A
148.150.203.189
255.255.255.0
10.0.0.2
255.255.255.0
Dependent B
148.150.203.188
255.255.255.0
10.0.0.3
255.255.255.0
Dependent C
148.150.203.187
255.255.255.0
10.0.0.4
255.255.255.0
* If you plan to connect to a corporate network, ask your network administrator for a configuration.
