Load Frame Dimensions and Weights
MTS Criterion
®
Series 40 Lifting and Moving Instructions
7
Load Frame Dimensions and Weights
The following table provides the dimensions of various load frame models. If
you transfer the load frame to its final site location after unpacking the system,
then use these dimensions to ensure that the frame fits through all doorways and
hallways.
Load Frame Dimensions
M ODEL W IDTH D EPTH H EIGHT W EIGHT
C41.103 560 mm
(22.05 in) 530 mm
(20.87 in) 1520 mm
(59.84 in) 60 kg
(176 lb)
C42.503 704 mm
(27.72 in) 636 mm
(25.04 in) 1332 mm
(52.44 in) 112 kg
(246.4 lb)
C42.503E 704 mm
(27.72 in) 636 mm
(25.04 in) 1632 mm
(64.25 in) 125 kg
(275 lb)
C43.104 794 mm
(31.26 in) 757 mm
(29.8 in) 1616 mm
(63.62 in) 175 kg
(385 lb)
C43.104E 794 mm
(31.26 in) 757 mm
(29.8 in) 1916 mm
(75.43 in) 190 kg
(418 lb)
C43.304; C43.504 826 mm
(32.52 in) 768 mm
(30.24 in) 1752 mm
(68.97 in) 305 kg
(671 lb)
C43.304E; C43.504E 826 mm
(32.52 in) 768 mm
(30.24 in) 2052 mm
(80.79 in) 325 kg
(715 lb)
C44.104 870 mm
(34.25 in) 700 mm
(27.56 in) 1951 mm
(76.8 in) 367 kg
(807.4 lb)
C44.104E 870 mm
(33.9 in) 700 mm
(27.56 in) 1951 mm
(76.8 in) 383 kg
(842.6 lb)
C44.304 870 mm
(33.9 in) 700 mm
(27.56 in) 2251 mm
(88.60 in) 395 kg
(869 lb)
C44.304E 870 mm
(33.9 in) 700 mm
(27.56 in) 2251 mm
(88.60 in) 410 kg
(902 lb)
C45.504; C45.105 1315 mm
(51.77 in) 957 mm
(37.68 in) 2269 mm
(89.3 in) 1195 kg
(2629 lb)
C45.504E; C45.105E 1314 mm
(51.73 in) 957 mm
(37.68 in) 2569 mm
(101.1 in) 1265 kg
(2783 lb)
C45.504W 1710 mm
(67.32 in) 957 mm
(37.68 in) 2569 mm
(101.1 in) 1700 kg
(3748 lb)
C45.305 1362 mm
(53.62 in) 1100 mm
(43.31 in) 2535mm
(99.80 in) 1660 kg
(3660 lb)
C45.305E 1362 mm
(53.62 in) 1100 mm
(43.31 in) 2835 mm
(111.57 in) 1700 kg
(3848 lb)
C45.605 1660 mm
(65.35 in) 1272 mm
(50.08 in) 3490 mm
(137.40 in) 3500 kg
(7716 lb)
