Introduction, Introduction 3 – MTS Multi-Pump Control Manager Remote Human-Machine Interface User Manual
Page 5
Remote Human Machine Interface
Introduction
3
Introduction
The Remote Human Machine Interface (RHMI) allows you to operate a single
Hydraulic Power Unit (HPU) remotely. The RHMI comes in two configurations:
a standalone unit and a pedestal mount unit. The standalone unit can be placed on
a table or mounted on the wall.
Note
The RHMI can only be used on the G2 HPU models. It will not work with
the older HPU models. Contact MTS for additional information.
There is one RHMI per one HPU. The RHMI can be located away from the HPU
in a location of your choice; for example a control room or laboratory.
Intended use
The intended use is to provide remote operation and status information for a
HPU.
