MTS Multi-Pump Control Manager Remote Human-Machine Interface User Manual
Page 19

Main Screen
Remote Human Machine Interface
Operation
17
Oil Flow (optional)
Indicator/Display: Displays the total hydraulic fluid flow form all
running pumps. A flow meter must be installed on the HPU for
this feature to be available.
Main
Pushbutton/Indicator. Pushbutton used to select the Main screen.
Main - gray: In this state, one of the other screens is selected; for
example the Status screen.
Main - black: The Main screen is selected and displayed.
Status
Pushbutton/Indicator. Pushbutton used to select the Status screen.
Status - gray: In this state, one of the other screens is selected; for
example the Main screen.
Status - black: The Status screen is selected and displayed.
Status - blue: A blue indicator means action is required. When the
status indicator is blue, press the status button to go to the status
screen and resolve any condition that requires action.
Auto Setup
Display only.
Auto Setup - gray: In this state, one of the other screens is
selected; for example the Main screen.
Auto Setup- black: The Auto Setup screen is selected and
displayed.
Name and Location
Description
