Specifications
Series 247 Actuators Introduction 21
Series 247 Actuator Dimensions
The letters in the following tables correspond to the letters in the “Series 247
Actuator Dimensions” on page 21.
Actuator Dimensions
Model D E
SI Metric U.S. Customary mm in
247.11 M27x2 mm 1-14 UNS 50.8 2
247.12 M27x2 mm 1-14 UNS 50.8 2
247.21 M27x2 mm 1-14 UNS 50.8 2
247.22 M27x2 mm 1-14 UNS 50.8 2
247.23 M27x2 mm 1-14 UNS 50.8 2
247.31 M36x2 mm 2-12 UNS 63.5 2.5
Front End Cap Dimensions
Model
F
*
* The holes are evenly spaced on the diameter of “I”.
G
H I
mm in mm in
247.11 4 3/8-16 UNC 19.1 0.75 81.3 3.2
247.12 4 3/8-16 UNC 19.1 0.75 81.3 3.2
247.21 8 1/2-13 UNC 19.1 0.75 104.1 4.1
247.22 8 1/2-13 UNC 19.1 0.75 104.1 4.1
247.23 8 1/2-13 UNC 19.1 0.75 104.1 4.1
247.31 8 5/8-11 UNC 25.4 1 139.7 5.5
Rear End Cap Dimensions
Model
F *
* The holes are evenly spaced on the diameter of “I”.
G
H I
mm in mm in
247.11 4 3/8-16 UNC 19.1 0.75 88.9 3.5
247.12 4 3/8-16 UNC 19.1 0.75 88.9 3.5
247.21 4 5/8-11 UNC 25.4 1 127 5
247.22 4 5/8-11 UNC 25.4 1 127 5
247.23 4 5/8-11 UNC 25.4 1 127 5
247.31 4 7/8-9 UNC 36.5 1.4 191.7 7.53
