Specifications, Specifications 19 – MTS Series 247 Actuators User Manual
Page 19
Specifications
Series 247 Actuators
Introduction
19
Specifications
This section lists the specifications and dimensions for the Series 247 Actuator.
Single-Ended Actuator Specifications
Model
Force Rating
*
*
Nominal force with 21 MPa (3000 psi) hydraulic pressure.
Effective Piston Area
Rod Diameter
Tension
Compression
Tension
Compression
kN
kip
kN
kip
cm
2
in
2
cm
2
in
2
mm
in
247.11
16.1
3.6
48
10.8 7.81
1.21
23.23
3.6
44.5
1.75
247.12
27.9
6.3
59.9
13.5
13.45
2.09
28.97
4.49
44.5
1.75
247.21
51.8
11.6
131
29.5
25.03
3.88
63.36
9.82
69.9
2.75
247.22
100.8
22.7
180
40.5
48.7
7.55
87.02
13.49
69.9
2.75
247.23
169.5
38.1
248.7
55.9
81.91
12.7
120.23
18.64
69.9
2.75
247.31
261.6
58.8
408.9
91.9
126.4
19.6
197.68
30.64
95.3
3.75
