242 Actuator Force Specifications
Series 242 Actuator Product Information
Introduction
19
242 Actuator Force Specifications
242 Actuator Dimensions
Actuator Force Specifications
M
ODEL
*
F
ORCE
R
ATING
†
P
ISTON
A
REA
R
OD
D
IAMETER
K
N
K
IP
MM
2
IN
2
MM
IN
242.00
2.7
0.6
136
0.21
28.6
1.12
242.01
4.5
1.0
271
0.42
28.6
1.12
242.02
10.0
2.2
594
0.92
28.6
1.12
242.03
15.0
3.3
760
1.18
28.6
1.12
* Each model has a standard stroke length of 101.6 and 152.4 mm (4
and 6 in). This value is total stroke minus the total cushion length, 12.7
mm (0.50 in). Optional stroke length in 25.4 and 50.8 mm (1.00 and
2.00 in).
† Nominal force with 17.2 MPa (2500 psi) pressure drop across the
piston. Actual force may be up to 20% higher depending on servovalve
size and test conditions.
Actuator Dimensions
D
YNAMIC
S
TROKE
(A
LL
M
ODELS
)
D
IMENSIONS
*
A
B
C
MM
IN
MM
IN
MM
IN
MM
IN
25.4
1
40.64
1.6
215.9
8.5
322.07
12.68
50.8
2
66.04
1.6
215.9
8.5
347.47
13.68
101.6
4
116.84
4.6
279.4
11.0
461.77
18.18
152.4
6
167.64
6.6
660.2
13.0
563.37
22.18
* The dimensions listed are shown in the following figure.
