Series 242 Actuator Component Identification
Series 242 Actuator Product Information
Introduction
15
Series 242 Actuator Component Identification
Series 242 Linear Actuator
Piston Rod End
Pedestal Base
Retraction Port
Extension Port
Piston Rod
Drainback Port
Piston Rod Seal
LVDT Assembly
Piston Rod Seal
Cushion
Cushion
Piston Rod Bearings
LVDT Connector
Viscous Seal
Spacer Tube
