MK Diamond CX-3 - Manual (Page 19)

19
(J)
When the cut is complete, raise the
Blade. Close Cooling Supply Valve
and shut down saw.
CX-3
®
SHUTDOWN
Normal Engine Shutdown
(A)
Raise the Blade the ground.
(B)
Move the Throttle Lever to lower
blade speed.
(C)
Place Engine Master Switch in
the OFF position. Place Fuel
Valve in the OFF position.
Refer to Engine Manual.
(D)
Raise the Pointer.
NOTE: Perform the cut using only enough pressure to follow the
original marked line. The saw has a natural tendency to
pull towards the side on which the blade is mounted. To
assure straight line cutting, apply pressure to the appropri-
ate handle. If excessive pressure is required back off the
on the forward speed of the saw. Driving the saw too fast
while cutting may cause the front wheels to lift causing the
blade to cut at uneven depths. Do not attempt to steer the
saw. Sudden and severe corrections can cause the blade
to be damaged or broken.
