11
CX-3 ® PRODUCT SPECIFICATION
Blade
The CX-3 ®
uses a 12 to 14 inch diameter diamond blade.
Concrete Saw Usage
The CX-3 ®
is designed to cut various grades of concrete surfaces.
Features
• Compact, lightweight, engineered for maneuverability and reliability
• Can be used for wet or dry cutting
• Corrosion resistant cast-aluminum blade guard
• Built-in water distribution system supplies water to both sides of blade
• Blade guard mounts on either left- or right-hand side of saw and cuts within 1” of wall or curb
• Sturdy single piece steel motor mount weldment to minimize vibration
• 1” diameter blade shaft with self aligning bearings
• Hinged blade guard provides easy access for blade changes and inspection
• Folding handle bar for compact transport
• Poly V-belt for positive power transmission
PRODUCT SPECIFICATIONS
The CX-3 ® is a versatile gas powered Concrete Saw. Operated and used according to this manual,
the CX-3 ® will provide years of dependable service.
General Description
The CX-3 ® is engineered as a portable concrete saw powered by a Subaru, Honda or Kohler gas
engine. The saw is capable of cutting up to five and half (5-1/2) inches in depth.
Motor and Weight Specifications
Motor and Weight specifications for the CX-3 ® are listed below.
Motor Type 4-Stroke, Overhead valve, single cylinder
Max RPM 3600 RPM
Blade Speed 3400 to 3600 RPM (Depending on Blade Diameter)
Fuel Tank Capacity
See Engine Manual for details
Engine Oil Capacity
Weight
Approximately 116 lbs.
