MK Diamond MK-2000 Gas - Manual (Page 55)

55
MK-2000 GAS SAW EXPLODED VIEW & PARTS LIST
ItEM DESCRIPTION PARt # QTY.
1 FLANGE, OUTER 132290 1
2 WASHER, FLAT, SAE, 3/8 150923 4
3 WASHER, LOCK, SPLIT, 5/16 151747 4
4 SCREW, HEX HD 1/2-20X1-1/4 152122 1
5 SCREW, HEX, 5/16-18 X 2-1/4 153951 4
6 BEARING, ARBOR HOUSING 154594 2
7 CASTING, 2000/5000 ARBOR - COMP 154637 1
8 SHAFT, BLADE 154639 1
9 FLANGE, ARBOR, INNER 154640 1
1
4
6
7
8
9
Assy. Arbor Part # 154636
