background image

29

TRACK RAIL SAW

PARTS LIST

Cutting Head Assembly

ITEM

NO.

DESCRIPTION

PART OR

IDENTIFYING NO.

QTY.

REQ.

1

SCREW, 5/16-18 X 1 HEX HEAD MACHINE

151743

2

2

WASHER, 5/16 SPLIT LOCK

151747

2

3

WASHER, 5/16 SAE FLAT

151754

2

4

LABEL, CAUTION, SAFETY

155576

1

5

FILTER, MOTOR

157729

1

6

CAP, MOTOR

157877

1

7

SPACER, NYLON

157878

1

8

SPACE, CAP SCREW

157879

2

9

FLANGE, Ø 3.0 INNER

158106

1

10

SCREW, #8 X 1-1/2 FLAT HD PHIL

158157

2

11

ASSY, MOTOR, 115V/3A

160251

1

12

LABEL, WARNING, SILICA, PROP 65

164202

1

13

PIN, PIVOT

164934

1

14

SPRING, 70’ TORSION

165272

1
