MK Diamond MK-1590 User Manual
Page 21
21
TRACK RAIL SAW
MAINTENANCE
Roller Wheel Replacement
1. Remove the Hex Screws (A) and Round Knob (B).
2. Remove Motor and Blade Guard Assembly from the Carrier Assembly.
3. Remove Carrier Assembly from the Rail Assembly. Place the Carrier Assembly on a flat and
level surface.
A
A
B
WARNING
Disconnect the unit from the power supply.
