MK-770
Revision 06/05, Effective Date June 17, 2005
Page 37
EXPLODED VIEW AND PARTS LIST
Item
Description
Qty
Part #
G
Linear Bearing
151737-MK
G1
Casting, Bearing, Linear (comp)
1
151737
G1a
Bearing, Multi-Lube
2
151781
G2
Screw, 5/16-18 x 1 Hex Head Cap
2
151743
G3
Washer, 5/16 Split Lock
2
151747
G4
Washer, 5/16 SAE Flat
2
151754
H
120v Motor
1
n/a
H1
H1A
Motor, 120v/7.4A
Motor, 240v/2.7A, 770
1
1
156428-R
157054
H2
Label, Caution, GFCI, 1 X 2 1/8
1
155678
H3
Label, Caution, Receptacle, 1 X 2 1/8
1
154822
H4
Screw, 10-32 X 5/8 Flat Head Phillips Cap,
4
157554
H5
Flange, Blade
2
135830
H6
Nut, 5/8-18 UNF
1
135848
H7
Label, Motor MK-770
1
156691
H8
Plug, CEE 7/7 16a 240v
1
153687
H9
Plug, 340v/10A Australia
1
156267
J
Motor Mount
n/a
J1
Casting, Motor Mount, (comp)
1
153904
J2
Washer, 5/16 Split Lock
1
151747
J3
Screw, 5/16-18 x 2 1/2 Hex Head Cap, Full Thread
1
151748
J4
Knob, Davies
1
151681
J5
Bolt, Shoulder, Soc. Hd ½ x ½“
2
151753
J6
Bolt, Shoulder, Soc. Hd 5/16-18 x 5/8
1
152137
J7
Washer, Flat SAE 5/16”
2
151754
K
Post
n/a
K1
Casting, Post (comp)
1
153516
K2
Screw, 3/8-16 x 2”, Hex Head
2
153485
K3
Screw, 3/8-16 x 1”, Hex Head
1
152507
K4
Screw, 1/4-20 x 1”, Hex Head
1
152676
K5
Nut, 1/4-20, Hex
1
151893
K6
Washer, Lock, 3/8
3
150925
K7
Washer, Flat SAE 3/8
3
150923
K8
Knob, Tri-Plastic
1
156770-04
K9
Label, 770
1
155395
K10
Label, MK-Diamond Logo
1
151969
L
Roller Wheel
151756
L1
Bracket, Roller Wheel
1
154021
L2
Wheel, Roller
1
151799
L3
Screw, 1/4-20 x 1 1/2 Hex Head Cap
1
151914
L4
Washer, 1/4 SAE Flat
1
151915
L5
Nut, 1/4-20 Hex
1
151893
M
Table, 770
n/a
M1
Casting, Table, comp
1
151738
M2
Screw, 5/16-18 x 1 Hex Head Cap
2
151743
M3
Washer, 5/16 Split Lock
2
151747
M4
Washer, 5/16 SAE Flat
2
151754
