Page 36
MK-770
Revision 06/05, Effective Date June 17, 2005
Page 36
EXPLODED VIEW AND PARTS LIST
PARTS LIST:
Item
Description
Qty
Part #
A
Accessories
n/a
A1
Carton, Accessory pack, 770
1
153498
A2
Wrench, Blade Nut, 15/16 Boxed End
1
134684
A3
Wrench, Blade Shaft, 11/16 Open End
1
153450
A4
Curtain, Splash
1
134841
A5
Bracket, Splash Curtain
1
155901
A6
Wing-screw, 1/4-20 x 1/2
1
151888
A7
Casting, Rip Guide (comp)
1
134551
A8
Screw, 1/4-20 X 3/4 Thumb
1
150991
A9
Pump, 120v Water
1
151271
A10
Fitting, Plastic, 1/4 FNPT x 1/4 BARB
1
128397
A11
Hose, Vinyl, 1/4 ID
2 1/2’
132951
A12
Clamp, Flow, 1/4-1/2
1
154394
A13
Owner’s Manual, Water Pump, G-150A
1
155745
A14
Plug, Nema 5-15P 15a/120v
1
150869
A15
Blade, 7 x 060 x 5/8, MK-100 (saws)
1
153441
A16
Owner’s Manual, 770
1
153618
A17
Warranty Card
1
155037
B
Blade Guard
154811-MK
B1
Casting, Guard, 7” Blade, (comp)
1
154811
B2
Elbow, 1/8 MNPT x 1/4” Barb 90° Brass
1
154652
B3
Knob, Davies
1
151681
B4
Washer, 5/16 SAE Flat
2
151754
B5
Wing-nut, 5/16-18 Nylock
1
151746
D
Cutting Head
n/a
D1
Casting, Cutting Head (comp)
1
151733
D2
Helicoil, 3/8-16
1
151880
D3
Screw, Slotted Pan Hd 10-32 x 1/4”
1
151750
D4
Screw, Slotted Pan Hd 10-32 x 1”
1
151751
D5
Nut, Hex 10-32
2
151749
D6
Label, Warning, Safety
1
155806
D7
Label, MK-USA
1
154334
D8
Tag, Serial Number MK-770
1
156546
E
Frame
n/a
E1
Frame
1
153322
E2
Pan, Plastic
1
151736
E3
Plug, Water Drain
1
153439
E4
Plate, Adjustment
2
151758
E5
Pin, Rolled
2
151783
F
Guide Bar, 5/8 Dia.
151739-MK
F1
Bar, Guide, 5/8 Dia.
1
151739
F2
Cover, 5/8 Guide Bar
1
151740
F3
Spacer, 5/8 Guide Bar Cover
2
151755
F4
Screw, 5/16-18 x 1 Hex Head Cap
2
151743
F5
Washer, 5/16 Split Lock
2
151747
F6
Washer, 5/16 SAE Flat
2
151754
