MK-770 Revision 06/05, Effective Date June 17, 2005 Page 10
SAFETY
PRODUCT SPECIFICATIONS:
The MK-770 is a versatile Tile Saw. Operated and used according to this manual, the MK-770 will provide
years of dependable service.
General Description:
The MK-770 Tile Saw is engineered as a tabletop or stand mounted wet tile saw. The saw includes a powerful
115v electric motor. The saw is capable of cutting tile up to fourteen (14) inches in length, or diagonal cutting
tile up to ten (10) inches. The saw can cut an object one and one-half (2) inches thick in one pass.
Motor Specifications:
Motor specifications for the MK-770 are listed in Table 2 below.
Voltage 115 v
Overall Amperage 7.4 A
Frequency 60 Hz
RPM 6000 rpm
Horse Power 1-1/4 hp
Weight 46 lbs
Table 2
Blade Capacity:
The MK-770 uses a 7 (7) inch (178mm) diameter, wet cutting continuous rim, MK Diamond blade with a five-
eighths (5/8) inch (15.875 mm) arbor.
Tile Types:
The MK-770 can cut a variety of tile types including Porcelain, Terracotta, Marble, Quarry and Slate, Ceramic
or almost any other non-ferrous material.
NOTE:
The MK-770 is not designed to cut plastic or ferrous (metals) material.
