T13-b P
anel
o
verview
T13-B ROOF PANEL PROFILE
T13-B WALL PANEL PROFILE
SLOPE
SUBSTRATE
COVERAGE
LENGTH
AVAILABILITY
APPLICATION
FASTENING SYSTEM
FASTENERS
MATERIALS
FINISHES
The minimum recommended slope for any T13-B roof panel is 1:12. Metal Sales recommends that in all roof
applications sealant be used on sidelaps.
T13-B panel is designed to be utilized over open structural framing, but can easily be used with a solid sub-
strate. The recommended substrate is
5
/
8
" plywood with a 30 pound felt moisture barrier. To avoid panel distor-
tion, use a properly aligned and uniform substructure.
Each panel has a coverage of 30"
Lengths under 5'-0" are available with some cutting restrictions. Maximum recommended panel length is 45'-
0". Longer panels require additional consideration in packaging, shipping, and erection. Please consult your
Metal Sales branch for recommendations (see PGI-2 and PGI-3 for locations).
Commercial, Industrial, and Architectural panels.
Direct Fastened (exposed).
The fastener selection guide should be consulted for choosing proper fasteners for specific applications. Quan-
tity and type of fastener must meet necessary loading and code requirements (see PGI-12-14).
Steel grade 50, per ASTM A-792, Optional material: stainless steel, copper, and aluminum.
Panels are available in 24 through 16 gauge. Minimum quantities may apply.
Custom capabilities include:
-Crimp curving on numerous panel profiles.
-Curving may be convex, concave, or "S" curves.
-Perforated panels for wind screens and liner panels.
*
Acrylic Coated Galvalume
®
(ACG) / ASTM A-792 - AZ55
Multi-Pass Kynar
Prepainted Galvalume / ASTM A-792 - AZ50
Marbilique
MS Colorfast45
®
Plastisol
**
Fluorocarbon (PVDF)
Polyester
*
Differential appearance of Acrylic Coated Galvalume roofing materials is not a cause for rejection.
**
Meets both Kynar 500 and Hylar 5000 specifications.
C
30" Coverage
10" Pitch
3"
2
3
/
8
"
7
5
/
8
"
C
30" Coverage
10" Pitch
3"
2
3
/
8
"
7
5
/
8
"
