Metal Sales TDR-6 User Manual
Page 22
PI/D-22
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
I
ndustrIal
r
Ib
/ d
eep
r
Ib
s
erIes
v
alley
D
eTail
r
ake
D
eTail
Valley Plate (by others)
3" Minimum
Valley
Rake Angle (by others)
Tape Sealant
#12-14 x 1
1
/
4
" SD
Inside Closure (bevel cut)
Roof Panel (bevel cut in field)
Tape Sealant
Custom Rake
#12-14 x 1
1
/
2
" SD
1
/
4
"-14 x
7
/
8
" Stitch (1'-0" o.c.)
Cleat
Roof Panel
Wall Panel
Tape Sealant (optional)
Outside Closure
1
/
8
x
3
/
16
" Pop-Rivet (1'-0" o.c.)
#12-14 x 1
1
/
2
" SD
i
nDusTrial
r
ib
/ D
eeP
r
ib
s
eries
CL
