Metal Sales TDR-6 User Manual
Page 31
PI/D-31
I
ndustrIal
r
Ib
/ d
eep
r
Ib
s
erIes
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
J
amb
D
eTail
(v
erTiCal
)
J
amb
D
eTail
(h
orizonTal
)
#12-14 x 1
1
/
4
" SD (1'-0" o.c.)
Wall Panel
Head/Jamb Cover
#12-14 x 1
1
/
4
" SD
Inside Closure
Wall Panel
Tape Sealant (optional)
Custom Jamb
Head/Jamb Cover
Custom Jamb
