Metal Sales T6-A User Manual
Page 21
PEF-21
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
E
xposEd
F
astEnEd
p
anEl
s
EriEs
s
ill
/h
ead
d
eTail
(v
erTiCal
)
s
ill
/h
ead
d
eTail
(h
orizonTal
)
Tape Sealant (optional)
Custom Sill/Head
#12-14 x 1
1
/
4
" SD
Inside Closure
Wall Panel
Head/Jamb Cover
#12-14 x 1
1
/
4
" SD
Wall Panel
#12-14 x 1
1
/
4
" SD (1'-0" o.c.)
Custom Sill/Head
Head/Jamb Cover
e
xPosed
f
asTened
P
anel
s
eries
