Metal Sales T6-A User Manual
Page 20
PEF-20
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
E
xposEd
F
astEnEd
p
anEl
s
EriEs
i
nside
C
orner
d
eTail
(v
erTiCal
)
i
nside
C
orner
d
eTail
(h
orizonTal
)
Tape Sealant (optional)
#12-14 x 1
1
/
4
" SD
1
/
4
"-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
Inside Corner
Wall Panel
1
/
8
" x
3
/
16
" Pop-Rivet (1'-0" o.c.)
1
/
4
"-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
Metal Closure
(field cut and formed)
Detail Optional
e
xPosed
f
asTened
P
anel
s
eries
Tape Sealant (optional)
Inside Corner
#12-14 x 1
1
/
4
" SD
1
/
4
"-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
Wall Panel
Outside Closure
#12-14 x 1
1
/
4
" SD
