Metal Sales T6-A User Manual
Page 16
PEF-16
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
E
xposEd
F
astEnEd
p
anEl
s
EriEs
r
akewall
d
eTail
e
ndwall
d
eTail
e
xPosed
f
asTened
P
anel
s
eries
1
/
4
"-14 x
7
/
8
" (1'-0" o.c.)
Roof Panel
#12-14 x 1
1
/
4
" SD
Inside Closure
Wall Panel
Rakewall
Tape Sealant
#12-14 x 1
1
/
4
" SD (1'-0" o.c.)
Roof Panel
Pitch Break
#12-14 x 1
1
/
4
" SD
1
/
4
"-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
Inside Closure
Wall Panel
Outside Closure
Tape Sealant
#12-14 x 1
1
/
4
" SD
Tape Sealant
