Metal Sales Stile Manual - Manual (Page 16)

PST-16
STILE ®
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
r
idge
/h
iP
d
eTail
sTile ®
Moisture Barrier (by others)
Stile Panel
Double Bead Tape Sealant
1 /
8
" x 3 /
16
" Pop-Rivet (every other rib)
1 /
4
"-14 x 1 1 /
2
" Woodscrew XL (see below)
Stile Closure
Ridge/Hip Cover
f
ormed
r
idge
/h
iP
d
eTail
Moisture Barrier (by others)
Stile Panel
Double Bead Tape Sealant
1 /
8
" x 3 /
16
" Pop-Rivet (every other rib)
1 /
4
"-14 x 1 1 /
2
" Woodscrew XL (see below)
Stile Closure / Stile Hip Closure
Formed Ridge/Hip Cover
3:12 Slope
Minimum
3:12 Slope
Minimum
1 /
4
"- 14 x 1 1 /
2
" Woodscrew XL
Stile Fastening Pattern
1 /
4
"- 14 x 1 1 /
2
" Woodscrew XL
Stile Fastening Pattern
