STILE ®
PST-15 © Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
e
ndwall wiTh
r
egleT
d
eTail
J
UnCTion
s
heeT
d
eTail
sTile ®
Moisture Barrier (by others)
Reglet Flashing
Stile Panel
Pitch Break
Double Bead Tape Sealant
1 /
8
" x 3 /
16
" Pop-Rivet (every other rib)
1 /
4
"-14 x 1 1 /
2
" Woodscrew XL (see below)
Fasteners (by others)
Stile Closure
Tube Sealant
Moisture Barrier (by others)
Junction Sheet
Stile Panel
Double Bead Tape Sealant
1 /
4
"-14 x 1 1 /
2
" Woodscrew XL (see below)
Fasteners (by others)
Counter Flashing
Tube Sealant
3:12 Slope
Minimum
3:12 Slope
Minimum
1 /
4
"- 14 x 1 1 /
2
" Woodscrew XL
Stile Fastening Pattern
1 /
4
"- 14 x 1 1 /
2
" Woodscrew XL
Stile Fastening Pattern
